This double decker bus air conditioner model is TKT-550ED. It is suitable for double decker bus.
✲ Cooling Capacity: 55KW / 187K BTU
✲ Competitive Price / Heating Optional
✲ Quality Trusted by BYD & TATA
✲ Higher Quality: Leading Global Brand Compressor / Copper Tube and Aluminum Fin, dll..
The type of air conditioner on the current page is electric bus air conditioner. It is designed for electric buses. It requires DC 280-750 power battery for power. If your bus is engine driven. It is not suitable for this air conditioner. We offer other solutions. Based on more than 20 Tahun-Tahun Pengalaman, this air conditioner with a cooling capacity of 187K BTU is suitable for electric double decker bus.
As an expert and leading manufacturer of Double Decker Bus Air Conditioner in China, TKT Busthermo has been supplied to YUTONG, Golden Dragon, Yaxing, Ankai, Neoplan, Hengtong, Shenlong, Foton and Nanjing Golden Dragon ect main bus manufacturer in China, and also do OEM to TATA Motor, TATA Marcopolo, Daewoo, Isuzu, MAZ, INCARVEN, MODABUS, GET ect bus manufacturer in the world. Those rich experience and over 20 years of market verification prove that TKT air conditioner is trustworthy. Currently we mainly provide rooftop all electric bus ac E-series for 6-12meters bus, suit for DC250V-DC750V bus input.
1. Designed 6 Condenser Fan to Guarantee the Fast Cooling even Ambient Temperature is more than 45 Deg. C
2. Adopting R410A Refrigerant to Achieve Super Cooling
3. Exclusive Design of Condenser Coil Structure with Design Patent to Get More Heat Release Area but Using Less Material
4. Running in China for 5 Year with ZERO Failure Rate
PS: OEM project for other length EV bus is available!
As a veteran bus air conditioner manufacturer, we are fully aware that you get what you pay for. TKT utilizes quality components to ensure that our products have superior performance and a longer lifespan. When you choose TKT Busthermo, you’re getting a reliable, top-of-the-line cooling solution.
| Cooling Capacity | 55 kW (187K BTU) Heating is Optional |
| Kompresor | Japan SANYO 80.5 cc/r |
| Refrigerant | R410 A/7 KG（On-site Filling） |
| Condenser QTY/Air Flow | 6 PCs/14400 m³/h |
| Evaporator QTY/Air Flow | (6 PCs+3 PCs)6000 m³/h+3000 m³/h |
| Power Supply/Rated Power | High-voltage Power Supply: DC450 V-780 V |
| Control Power Supply: DC24 V/10 A | |
| Dimensions | Condenser and Upper Evaporator：2000*750*1405 mm |
| Lower Evaporator：800*600*833 mm | |
| Weight | Condenser and Upper Evaporator：320 KG |
| Lower Evaporator：36 KG | |
| Product Standard | GB/T21361-2008(A/C for Automotive) |
| &TB/T1804 2003(A/C for Railway Coach) | |
| Safety Reference Standard | CJ/T 5007 Technical requirements for trolleybuses |
| CJ/T 5008 Test methods for trolleybuses | |
| GBT 18384.3-2015 Safety Requirements | |
| for Electric Vehicles | |
| Personnel Protection Against Electric Shock |
The leading bus air conditioner manufacturer in China! TKT has a team of 135 engineers. They include design engineers, structural engineers, electrical engineers, test engineers, dll.. They have complete design, development, and testing capabilities for commercial vehicle air conditioners and components.
Click for More Cases (Load HD Pictures, Wait Patiently)
TKT HVAC has a strict quality inspection process. Such as EMC electromagnetic test, piping air tightness test, drenching test, vibration test, finished product test and so on. This is all in order for you to get reliable bus air conditioners. (Click here to view Bus Rooftop Air Conditioner quality Inspection details)
You will get the following benefits.
1. Longer lifespan: more than 30% longer than low-end air conditioners
2. More stable operation: 45 degree outdoor temperature still stable operation
3. Factory sourced pricing
4. Customized OEM service
5. (Click to learn more benefits)
1. Why Choose us?
A. Reliable quality and competitive Price
B: Professional and well trained sales, and Technical support
C: Flexible payment terms
2. What is your Warranty Policy?
Firstly, we provide 18 months warranty from the date of delivery. Free spare parts will be provided if the parts defective for quality reason during the warranty period. But videos and fault description will be need for engineer double check first! Damage or defective caused by improper use not covered by warranty.
TKT HVAC was founded in 1998. So far, it has obtained many quality certificates such as ISO9001:2015, IATF16969:2016, CE, EMI/EMC, dll.. And owns more than 100 related patents.
Typically 7-10 days if in stock.
If there is no stock, it is usually in 3 weeks. Tentu saja, the specific situation depends on the order quantity and the task of our factory.
air conditioner for double decker bus, air conditioner for electric double decker bus, air conditioner for full electric double decker bus, air conditioner for new energy double decker bus, double decker bus air conditioner, full electric double decker bus air conditioner, double decker bus tours buffalo air conditioner.
Ini memperkenalkan secara rinci bagian-bagian penting dari AC bus dan prinsip kerja bagian-bagian penting. Mudah dimengerti dan sangat profesional.
TKT memiliki segudang solusi unit AC bus. Artikel ini memperkenalkan banyak pengetahuan dasar dan langkah-langkah pemasangan AC bus.
AC combine chiller project is an innovative design that integrates EV battery cooling system and electric bus air conditioning.
