7-22Pengecas EV AC kW

Pengecas AC EV ini mempunyai tahap perlindungan IP65 yang tinggi. Ia boleh dipasang di dinding atau dipasang di pangkalan.

Standard Penyambung: taip 1 / taip 2 / CHAdeMO / GBT

Protokol Komunikasi: OCPP1.6J

Pensijilan Kualiti: ISO9001, IATF16949, CE, dll.

Permohonan: Kawasan Kediaman, Syarikat, Tempat Komersil, Tempat Letak Kereta Awam, dan lain-lain.

Kongsi

AC EV Charger Overview

This AC EV Charger achieve Level 2 charging speeds (7kw / 11kw / 22kw). This allows you to charge your electric vehicle 5 to 7 times faster compared to a Level 1 charger. We have a wide range of product models to choose from, supporting a variety of installation methods.

We have formed long-term and stable cooperative relations with well-known Chinese enterprises such as Yutong Bus, Zhongtong Bus, BYD Automobile, and Ningde Times. Di pasaran antarabangsa, we have formed long-term and stable cooperation with Taiwan Yuandian Technology, Turkey Lumhouse, India Tata, India BYD, dan lain-lain.



AC EV Charger Specification Table

Sila tinggalkan mesej E-mel:md@tkt-hvac.com dan biarkan pakar kami memberi anda nasihat pakar. Kami menyokong penyesuaian OEM.

AC EV Charger

Sijil ISO9001, IATF16949, TUV, CE, IEC61851-1,IEC 62196-2
Charging Interface CCS1 Type 1 / CCS2 Type 2 / CHAdeMO Type 1
* 1 atau 2 Pilihan
Output Rating 7kW, 32A 11kW, 32A 22kW, 32A
Kecekapan ≥95%
Voltan Masukan 1-phase 230V ±20% 3-phase 400V ±20%
Standby Power < 5 W
Protection Degree IP 65
Internal Residual
Current Detection
Dual CE Certified RCCB Type-B (30mA AC, 6mA DC)
Over Current Protection Dual MCB 50A
Lightning Protection SPD 40KA
Energy Meter CE & MID Certified
Electrical Protection Over current, short circuit, over voltage, under voltage,
ground fault, lightning surge, over temperature
Mounting Type Wall-Mount or Pole-Mount or Floor-Mount
Network Interface 4G / Wi-Fi / Ethernet
OCPP OCPP 1.6J & OCPP 2.0
Status Indicators Standby (Green),Mengecas (Flashing Green), Fault (Red), Waring (Flash Red)
Paparan 2.8” LCD / 7″ LCD Display
User Authentication RFID / Applets / Credit Card (pilihan)
Buttons/Switches Physical button for charging connector selection, and also output current adjustment
Operating Temperature (-30℃ to +55℃) in operation, (-40℃ to +80℃) in storage
Bahasa cina, Inggeris, bahasa Rusia, Bahasa lain menyokong penyesuaian

TKT AC EV Charger Advantages

1. Pay attention to safety: safety first

Excellent protection system: TKT charging pile has protection functions such as leakage, overload, surge, lebihan voltan, undervoltage, short circuit, grounding, overheating, lightning strike, and emergency stop. So many protection functions are only for 100% personal safety. No amount of cost is too much.
Strong and durable shell: TKT adopts a combined process of galvanized sheet + multi-layer spraying process + first-level sealing. The equipment can reach IP54/IP55 protection level, moisture-proof, mildew-proof, rain-proof, rust-proof, dust-proof, and flame-retardant. The multi-layer coating process adopts anti-ultraviolet treatment to inhibit the aging of the cabinet and ensure a longer life cycle of the product.

2. Tahap 2 kelajuan pengecasan

We have rich and professional technology accumulation. The AC charging pile product series all reach level 2 charging and charging, with optional output power of 7kW/11kW/22kW. If there are special needs, we support customization.
Untuk merasakan kelajuan pengecasan dengan lebih intuitif. Saya membuat borang. Saya akan menggunakan 65kwj sebagai contoh. (If you can’t calculate, pakar kami boleh membantu, sila hubungi pakar)

AC EV Charger

Kapasiti Bateri Kenderaan Elektrik Kelajuan Mengecas Jumlah Masa untuk Mengecas Penuh Purata Batu Diperolehi Sejam
65kwh Tahap 1 kelajuan: 3kw 21.67h 10.5mi / 16.8km
Tahap 2 kelajuan: 7kw 9.29h 24.5mi / 39.2km
Tahap 2 kelajuan: 11kw 5.91h 38.5mi / 61.6km
Tahap 2 kelajuan: 22kw
(Supports 22kw simultaneous charging of 2 cars)
2.95h 77mi / 123.2km
Tahap 3 kelajuan: 180kw
Ketahui Lebih Lanjut
22min 630mi / 1008km

Note that actual charging time and increased range may vary depending on vehicle charging efficiency, battery temperature and other factors. These figures are based on ideal conditions.

3. Small and easy to install

Professional structural engineers design repeatedly to make the product compact and smaller. Under the same area, more equipment can be placed. The input side only needs to be connected to the grid, and the installation is very convenient.

Pemasangan yang mudah

4. Sistem Pengurusan Mudah dan Praktikal

Terminal pengguna: skrin sentuh LCD berwarna, menyokong pelbagai bahasa, simple design close to the owner’s use. Pelbagai kaedah pembayaran disokong.
Pihak pengurusan: pengurusan pintar, pemantauan jarak jauh, cepat dan mudah. Pelbagai statistik jelas. Mudah menyambung ke mana-mana bahagian belakang berasaskan OCPP.

Sistem Stesen Pengecas EV Komersial

5. Intelligent charging system

Supports load balancing and phase rotation functions. It can not only ensure the safe and stable operation of charging equipment, but also optimize the energy utilization efficiency of the power grid. As a leading charging pile manufacturer, ia mempunyai lebih daripada 10 tahun pengumpulan teknologi, lebih daripada 100 paten, menyokong OEM&ODM, menyediakan label putih, sistem pengurusan yang disesuaikan, dan lain-lain.

EV Charging patents

Strict Pre-delivery Inspection

We attach great importance to product quality, and we will conduct up to 16 inspections again before each delivery. These include wiring and routing, insulation resistance checks, circuit breaker and emergency stop function checks, internal power supply DC checks, touch screen checks, thermistor checks, fan function checks, charging history checks, remote communication function checks, dan banyak lagi.

DC EV charger factory inspection

tip pengeluar penghawa dingin rv

+ Soalan Lazim | Klik untuk lebih lanjut

Q: Can any electric car use a fast or rapid charger?

A: You don’t need to worry about this since electric automobile manufacturers have built-in safety systems to prevent damage from frequent use of rapid or fast charging. Sebagai contoh, the rate of charge can be automatically lowered if the car thinks too much power is being supplied to the battery too often.

Q: Apakah jaminan anda untuk pengecas EV?

A: Secara amnya 2 tahun. Jika anda mempunyai keperluan khas sila hubungi perkhidmatan pelanggan kami.

Q: Can you print our logo on the products?

A: Yes, we support OEM and ODM service, and there will be a MOQ for custom design.

Q: Berapa lama masa utama?

A: Masa utama ialah 30-45 hari bekerja, ia bergantung kepada kuantiti dan jadual pengeluaran.
